How to Rotate TDE master key on ExaCC with Data Guard
Introduction:
In this blog post I will show you how we can rotate TDE master key on ExaCC primary Database and then ensuring the standby database have the updated key.
Pre-Requisite:
Running Primary DB and Standby DB on ExaCC servers
Steps:
Rotate TDE master key on Primary DB (CDBPPRDG) with all PDBS:
[root@exacc2db1 ~]# dbaascli tde rotateMasterKey --dbname CDBPPRDG --rotateMasterKeyOnAllPDBs --prepareStandbyBlob true --blobLocation /tmp
DBAAS CLI version 25.1.1.0.0
Executing command tde rotateMasterKey --dbname CDBPPRDG --prepareStandbyBlob true --blobLocation /tmp
Job id: 5fe274d0-1b19-4ef4-a525-f18e18cd4127
Session log: /var/opt/oracle/log/CDBPPRDG/tde/rotateMasterKey/dbaastools_2025-05-02_03-51-45-PM_130246.log
Enter keystore password:
Loading PILOT...
Session ID of the current execution is: 24221
Log file location: /var/opt/oracle/log/CDBPPRDG/tde/rotateMasterKey/pilot_2025-05-02_03-54-27-PM_148013
-----------------
Running Plugin_initialization job
Enter SYS_PASSWORD: **********************
Enter keystore password: ******************
Completed Plugin_initialization job
-----------------
Running Perform_dbca_prechecks job
Completed Perform_dbca_prechecks job
-----------------
Running Standby_blob_extraction job
Skipping. Job is detected as not applicable.
-----------------
Running Rotate_tde_master_key job
Completed Rotate_tde_master_key job
-----------------
Running Generate_blob_file job
Completed Generate_blob_file job
---------- PLUGIN NOTES ----------
INFO: Rotate tde master key operation has been executed on the primary database. In order to successfully complete the operation, the file /tmp/CDBPPRDG_2025-05-02_03-54-27-PM_148013.tar needs to be copied to the standby database node and execute the rotate tde master key operation on standby database by specifying the copied file
---------- END OF PLUGIN NOTES ----------
dbaascli execution completed
You have new mail in /var/spool/mail/root
[root@exacc2db1 ~]#
See the Plugin Notes above: Above command will generate a tar file on /tmp location, we need to copied that file to standby side and then rotate key on standby using this file.
Rotate TDE master key on Standby DB (CDBPPRDG) with all PDBS:
[root@exacc1dev1 tmp]# dbaascli tde rotateMasterKey --dbname CDBPPRDG --standbyBlobFromPrimary /tmp/CDBPPRDG_2025-05-02_03-54-27-PM_148013.tar
DBAAS CLI version 25.1.1.0.0
Executing command tde rotateMasterKey --dbname CDBPPRDG --standbyBlobFromPrimary /tmp/CDBPPRDG_2025-05-02_03-54-27-PM_148013.tar
Job id: 7b2fa4b6-867b-436a-9588-e4f762db2041
Session log: /var/opt/oracle/log/CDBPPRDG/tde/rotateMasterKey/dbaastools_2025-05-02_04-09-34-PM_352001.log
Enter keystore password:
Loading PILOT...
Session ID of the current execution is: 22061
Log file location: /var/opt/oracle/log/CDBPPRDG/tde/rotateMasterKey/pilot_2025-05-02_04-10-11-PM_355445
-----------------
Running Plugin_initialization job
Enter SYS_PASSWORD: ******************
Enter keystore password: *******************
Completed Plugin_initialization job
-----------------
Running Perform_dbca_prechecks job
Completed Perform_dbca_prechecks job
-----------------
Running Standby_blob_extraction job
Completed Standby_blob_extraction job
-----------------
Running Rotate_tde_master_key job
Skipping. Job is detected as not applicable.
-----------------
Running Generate_blob_file job
Skipping. Job is detected as not applicable.
dbaascli execution completed
You have new mail in /var/spool/mail/root
[root@exacc1dev1 tmp]#
Verify:
We can use below command to verify the new key on both primary and standby side.
SQL> select key_id,tag,keystore_type,creation_time from v$encryption_keys;
KEY_ID TAG KEYSTORE_TYPE CREATION_TIME
------------------------------------------------------- ----- ----------------- ---------------------------------------------------------------------------
AYgixidfb09iv0OFyLrFVXUAAAAAAAAAAAAAAAAAAAAAAAAAAAAA SOFTWARE KEYSTORE 21-FEB-25 03.15.30.463980 PM -07:00
ATz4wxgh2E/PvzWdhAybFhAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA SOFTWARE KEYSTORE 21-FEB-25 03.06.47.522830 PM -07:00
Ac7Wvqd-H0/fv5MO0OYw1IUAAAAAAAAAAAAAAAAAAAAAAAAAAAAA SOFTWARE KEYSTORE 02-MAY-25 07.55.40.655571 PM UTC
NOTE Standby side will not show the new key unless we close the current TDE wallet and reopens the new password based wallet
SQL> ADMINISTER KEY MANAGEMENT SET KEYSTORE OPEN FORCE KEYSTORE IDENTIFIED BY "<password>";
keystore altered.
